Mains Frequency Spark Tester

Name: Mains Frequency Spark Tester
Brand: PURETRONICS INDIA PRIVATE LIMITED
Price: 78000 INR
Availability: InStock

Price 78000 INR/ Piece

Get a Price/Quote

MOQ : 1 Unit

Mains Frequency Spark Tester Specification

Usage
For Industrial Use

Power Supply
230V AC

Weight
80 Kilograms (kg)

Dimension (L*W*H)
600 W X 1400 H X 470 D Millimeter (mm)

Material
Mild Steel

Mains Frequency Spark Tester Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
1 Unit Per Day

Delivery Time
2 - 3 Days

About Mains Frequency Spark Tester

Our offered Mains Frequency Spark Tester is designed for testing the quality of power and automotive cable, insulation coated wires for pin holes, weak insulation, exposed conductor or widely used by cable manufacturer. These spark tester is manufactured by using superior grade technologies under the guidance of our expert professionals keeping in mind set quality norms. Apart from this, our provided Mains Frequency Spark Tester is available with industry-standard communications interfaces fitted either as standard or as option or available in rugged enclosure to service harsh industrial environment.

Technical Specification

Model	MFST-15/25/40KV
Voltage Range	1.5 to 15kv/25kv/40kv
Test Frequency	50/60hz (Same as supply Frequency)
Wire Size	0.5 T0 40mm 0.D (60mm on demand)
Electrode	Bead chain housing of 350mm long
Max Wire Speed	200mts/min
H.V Meter	Digital LED
Sensitivity	Selectable position switch/Adjustable knob
Fault Counter	6 digit LCD Self Powered
Power Supply	230v AC 50/60 Hz, 1KVA
Interlocking	By potential free change over
Safety	Door interlocking
Adjustable wire Running height	950mm to 1100mm from ground level
Dimension in MM(15kv)	820W x 1160H x 460D
Approximate Weight(15kv)	80 Kg

Robust Construction & Dimensions

Engineered from mild steel, the spark tester boasts a sturdy build and a compact footprint: 600 mm wide, 1400 mm high, and 470 mm deep. Its robust frame ensures durability and consistency in demanding industrial settings.

Optimized for Industrial Usage

Designed with the needs of industrial applications in mind, this spark tester operates efficiently on a 230V AC supply, complying with standard industrial power requirements and delivering reliable performance in insulation testing.

Quality Assurance in Manufacturing

As a trusted exporter, manufacturer, and supplier from India, we prioritize top-quality standards in every spark tester produced. Our device helps manufacturers ensure the integrity of their products, preventing faults and enhancing safety.

FAQs of Mains Frequency Spark Tester:

Q: How is the Mains Frequency Spark Tester used in industrial applications?

A: The spark tester is employed to assess insulation integrity in cables and wires during manufacturing, detecting faults or breakdowns by subjecting the material to high-voltage testing.

Q: What materials make up the construction of this spark tester?

A: The device is manufactured from mild steel, ensuring strength, durability, and resistance to wear in industrial environments.

Q: When should the Mains Frequency Spark Tester be operated?

A: It is recommended to use the spark tester during or after production runs for quality assurance, especially before shipment or installation of cables and insulation materials.

Q: Where is this spark tester manufactured and supplied from?

A: The product is designed, manufactured, and supplied by an established company in India, catering to clients both domestically and internationally.

Q: What is the process for the spark testing operation?

A: During operation, the tester applies a controlled high voltage to the material being examined. If insulation faults exist, these are detected instantly, allowing immediate corrective actions.

Q: How does using this tester benefit industrial manufacturers?

A: Utilizing the spark tester helps manufacturers assure their product quality, minimize defects, and comply with safety standards, thus increasing customer satisfaction and reducing warranty claims.
