Non Contact Length Measurement System

Non Contact Length Measurement System

Product Details:

  • Application Encoder Calibration
  • Product Type Length Measurement System
  • Voltage 110 - 230 VAC Volt (v)
  • Material Mild Steel
  • Color White
  • Supply Ability : 1 Piece Per Day
X

Price And Quantity

  • 1 Piece
  • INR

Product Specifications

  • White
  • Mild Steel
  • 110 - 230 VAC Volt (v)
  • Length Measurement System
  • Encoder Calibration

Trade Information

  • 1 Piece Per Day
  • 2 - 3 Days
  • Wooden Box
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • All India

Product Description

Technical Specification


μSPEED-PRO

μSPEED-SMART

μSPEED-SMART-ECO

Direction Detection

non-contact

via external direction signal

via external direction signal

Measurement starting from V=0

non-contact

optional

No

Material Presence

non-contact

optional

No

Accuracy (typ.)
(2σ;L>10m/3σ;L>20m)

± 0,05 %

± 0,05 %

± 0,3 %

Repeatability

± 0,02 % of the measurement value (except SMART-ECO)

Sensor Type

Smart Sensor

Smart Sensor

Smart Sensor

Speed Measurement Range

0 to ± 1.200 m/min
0-20 m/s

1 to ± 6.000 m/min
0,02-100 m/s

1 to ± 6.000 m/min
0,02-100 m/s

Stand-off Distance (Tolerances)

115±5 (±20) mm

120±5 (±20) mm
240±10 (±40) mm

120±5 (±20) mm
240±10 (±40) mm

Interfaces

1 x RS-485 or RS-232
alternatively to I/Os:
RS-422, RS-485

I/Os

Quadrature Output
1 to 100.000 (depending on maximum speed) pls/m
Input: Start, Gate, Direction, Laser Interlock
Output: Status

I/O Type

RS422 Gauge
Laser Interlock (single, 24V)

Available Data

speed, length, signal quality, status, laser interlock, valid measurement
material present (only PRO)

Fieldbus

Profibus, CANopen, DeviceNet, CCLink
EthernetIP, ProfinetIO, ModbusRTU
Bluetooth (All Fieldbus optional)

Class of Protection

Sensor Head: IP67
Controller/MID-COUNTER: Front: IP51; Back: IP20

Dimensions (LxWxH)

Sensor Head: 154x94x39 mm

Weight

Sensor Head: 0,9 kg

Power Supply

24 VDC (18 V to 30 V)

Operating Unit

optional

Laser Data

25 mW, 780 nm (Laser Class 3B)

Ambient Temperature/Humidity

5 to 55°C not condensing
beyond temperature range – external cooling / heating required
