DC Motor Controller

Name: DC Motor Controller
Brand: PURETRONICS INDIA PRIVATE LIMITED
Price: 16000 INR
Availability: InStock

Price 16000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

DC Motor Controller Specification

Measuring Range
03500 RPM

Power Supply
DC 12V / DC 24V

Test Range
0100% Motor Speed

Equipment Type
DC Motor Controller

Specimen Size
All Standard DC Motor Sizes

Interface Type
Screw Terminals

Automation Grade
Manual

Application
Variable Speed DC Motor Control

Port Size
Screw Terminal Blocks

Response Time
<100 ms

Number of Specimens
Supports 1 DC Motor

Temperature
-10C to 50C (Operating)

Humidity
2090% RH

Display Type
Digital LED

Resolution
1 RPM

Features
Overload Protection, Adjustable Speed, Compact Design

Accuracy
2% Motor Speed

Mounting Type
Panel Mount

Operating Voltage
12V/24V DC

Usage
Motor Speed Regulation

Capacity
Up to 20A Continuous

Machine Weight
Approx 750 g

Test Speed
03500 RPM (Adjustable)

Control Mode
PWM Control

DC Motor Controller Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1 Piece Per Day

Delivery Time
2-3 Week

Sample Available
Yes

Main Domestic Market
All India

About DC Motor Controller

DC Motor Controller is a smart and intelligent control unit that is commonly used to adjust the current flowing through the DC motors which in turn alters the rotational speed of the output shaft. It is designed and developed as per the electrical engineering standards that make it capable to operate at variable voltage levels. The circuit elements of the offered DC Motor Controller is encased in a rigid hard ABS plastic casing to prevent damages due to extreme temperature, pressure, and moist conditions.

Input Voltage : 24vdc
Output Voltage : 0 Vdc to 24Vdc
output current : 0 A to 5A
Communication : Modbus Protocol and RS 485 Serial Comunication

Advanced Motor Speed Regulation

Enjoy smooth and precise variable speed control for your DC motor applications, with adjustable settings ranging from 0 to 3500 RPM. The controller utilizes PWM technology to ensure optimal performance, and its digital LED display delivers accurate, real-time speed readings with 2% accuracy and a resolution of 1 RPM.

Robust Safety and Durability

Built with a blend of ABS plastic and metal, this controller incorporates integrated heatsink technology for efficient passive cooling. It features comprehensive protection against overcurrent and short circuits, supported by a 20A fuse. With its reliable construction, it guarantees safe and long-lasting operation under varied environmental conditions.

Effortless Installation and Interface

Designed for convenience, the controller uses screw terminal blocks for easy wiring and a panel mount configuration for secure placement. Suitable for both industrial and laboratory settings, it supports simple, manual automation grade usage by means of a potentiometer knob for speed adjustments.

FAQs of DC Motor Controller:

Q: How do I adjust the motor speed using this DC Motor Controller?

A: Motor speed is adjusted manually via the integrated potentiometer (knob). Turning the knob allows you to set the motor speed anywhere between 0 and 3500 RPM, with the real-time value displayed on the digital LED screen.

Q: What protection features are included to safeguard my equipment?

A: The controller is equipped with overcurrent and short-circuit protection, as well as a 20A fuse. These features help prevent damage to the controller and the connected DC motor, ensuring secure and reliable operation.

Q: Where is the DC Motor Controller typically mounted and how is it installed?

A: This controller is designed for panel mount installation. The compact design allows it to fit securely on control panels using screw terminal blocks for straightforward wiring and setup.

Q: Can I use this controller with any standard DC motor size?

A: Yes, the controller supports all standard DC motor sizes, provided the motors resistance is at least 0.5 and its current does not exceed 20A continuous.

Q: What are the operating conditions for optimal performance?

A: The controller operates effectively in temperature ranges from -10C to 50C and humidity levels from 20% to 90% RH. It requires a DC power supply of 12V or 24V.

Q: What benefits does PWM control offer in this device?

A: PWM (Pulse Width Modulation) control enables precise and efficient speed regulation, improves motor lifespan, reduces energy loss, and helps maintain consistent motor performance throughout the test range.
